Standard&Protocol IEEE802.3, , Interfaces 1*10/100/1000Mbps WAN port 3*10/100/1000Mbps LAN ports Antenna 5*external antennas Button 1*WPS/Reset button Power Input：AC 100-240V~50/60Hz Output:DC 12V⎓1A LED Indicator 1* LED Dimension 244*56*200mm(L*W*H) Wireless Standard IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz Data Rate 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) Frequency CE: 2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5350MHz(CH36-CH64) FCC: 2.4G: 2412-2462MHz(CH1-CH11) 5G: 5150-5350MHz(CH36-CH64) 5725-5850MHz(CH149-CH165) Transmission Power CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) Basic Features SSID broadcasting and hiding MU-MIMO Beamforming signal directional transmission technology 160MHz OFDMA 1024-QAM Wireless Security WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) fast encryption Internet Connection Type PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi Network Protocol IPv4&IPv6 Operating Mode Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） Parental Control Client Filter URL Filter Time Limit DHCP DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation Virtual Server Port Forwarding, DMZ Host, UPnP Firewall ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN DDNS DynDNS, no-ip, oray, 88ip VPN IPSec Transparent Transmission PPTP Transparent Transmission L2TP Transparent Transmission PPTP VPN Server PPTP VPN Client L2TP VPN Client Special Features Wi-Fi+(Mesh System) Smart diagnosis IPTV IPv6 Smart LED on/off Other Function Support App and web management Bandwidth Control Guest Network MAC Address Clone Supports black list and white list Unify 2.4 GHz & 5 GHz Static Routing Remote Web Management Backup & Restore configurations Firmware upgrade online Temperature Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ Humidity Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing Certification CE, FCC,RoHS Package Contents Wi-Fi Router *1 RJ45 Ethernet Cable*1 Power Adapter*1 Quick Installation Guide*1
