Graphics Processor GPU Name TU104 GPU Variant TU104-150-KC-A1 Architecture Turing Foundry TSMC Process Size 12 nm Transistors 13,600 million Density 25.0M / mm² Die Size 545 mm² Chip Package BGA-2228 Graphics Card Release Date Jan 10th, 2020 Generation GeForce 20 Predecessor GeForce 10 Successor GeForce 30 Production End-of-life Driver Support Active Bus Interface PCIe 3.0 x16 Clock Speeds Base Clock 1365 MHz Boost Clock 1680 MHz Memory Clock 1750 MHz 14 Gbps effective Memory Memory Size 6 GB Memory Type GDDR6 Memory Bus 192 bit Bandwidth 336.0 GB/s Render Config Shading Units 1920 TMUs 120 ROPs 48 SM Count 30 Tensor Cores 240 RT Cores 30 L1 Cache 64 KB (per SM) L2 Cache 3 MB Theoretical Performance Pixel Rate 80.64 GPixel/s Texture Rate 201.6 GTexel/s FP16 (half) 12.90 TFLOPS (2:1) FP32 (float) 6.451 TFLOPS FP64 (double) 201.6 GFLOPS (1:32) Board Design Slot Width Dual-slot Length 229 mm 222 mm 9 inches 8.7 inches Height 113 mm 126 mm 4.4 inches 5 inches Width 35 mm 42 mm 1.4 inches 1.7 inches TDP 160 W Suggested PSU 450 W Outputs 1x DVI 1x HDMI 2.0 2x DisplayPort 1.4a 1x USB Type-C 1x DVI 1x HDMI 2.0 1x DisplayPort 1.4a Power Connectors 1x 8-pin Board Number PG161 SKU 46 Graphics Features DirectX 12 Ultimate (12_2) OpenGL 4.6 OpenCL 3.0 Vulkan 1.4 CUDA 7.5 Shader Model 6.8
